frigidaire ice maker model efic117-ss manual

2.1. Installation Steps

Unpacking: Carefully unpack the ice maker and ensure all components are included and undamaged.
Location Setup: Place the unit on a flat, stable surface, ensuring proper ventilation and accessibility to a power outlet.
Water Supply Connection: Attach the water supply line to a nearby cold water source. Tighten all connections securely to prevent leaks.
Drain Hose Installation: Connect the drain hose to a nearby drain or a bucket to collect excess water.
Power Connection: Plug the ice maker into a grounded electrical outlet rated for 120V.
Initial Cooling: Allow the unit to cool for 2-3 hours before first use to ensure proper ice production.
Testing: Run a test cycle to verify ice production and address any issues promptly.
By following these steps, you can ensure a smooth and successful installation of your Frigidaire EFIC117-SS ice maker.

Operation

The Frigidaire EFIC117-SS ice maker operates by turning on the power switch, allowing water to flow into the reservoir, and automatically producing ice cubes. It features a simple control panel for easy operation and includes an automatic shut-off when the ice basket is full.

3.1. Modes of Operation

The Frigidaire EFIC117-SS ice maker offers multiple modes of operation to suit different needs. It includes a standard ice-making mode, a fast ice mode for quick production, and an energy-saving mode to reduce power consumption. The unit also features an automatic shut-off function when the ice basket is full, ensuring efficient operation. Additionally, it has a manual defrost mode to maintain performance and prevent ice buildup. The ice maker is designed to operate quietly, making it suitable for home or office use. Users can select the desired mode using the control panel, which includes indicators for power, ice full, and water level. The machine automatically adjusts water intake and freezing time based on the selected mode. For optimal performance, it is recommended to monitor the unit during operation and ensure proper water supply. Regular maintenance, such as cleaning and checking water filters, will help maintain its efficiency and extend its lifespan.

Maintenance

Regular maintenance ensures optimal performance and extends the lifespan of your Frigidaire ice maker. Clean the unit regularly, check and replace water filters, and ensure proper drainage. Dry the interior after cleaning to prevent mineral buildup. Always refer to the manual for detailed maintenance procedures.

4.1. Cleaning the Ice Maker

Cleaning your Frigidaire Ice Maker Model EFIC117-SS is essential for maintaining hygiene, preventing mineral buildup, and ensuring fresh-tasting ice. Follow these steps to clean your unit effectively.

• Turn off the ice maker and unplug it from the power source to avoid any accidents or electrical issues.
• Remove any existing ice from the ice bucket and wash it with warm soapy water. Rinse thoroughly and dry before replacing it.
• Mix a cleaning solution of 1 cup white vinegar to 1 gallon of water. This solution helps remove lime scale and sanitize the interior.
• Wipe down the exterior with a soft cloth and mild soap to remove any splatters or stains.
• Run the cleaning solution through the ice maker by pouring it into the water reservoir. Let it cycle through to clean the internal components.
• Rinse thoroughly by running fresh water through the system to remove any vinegar taste or residue.
• Dry the interior with a clean towel to prevent moisture buildup and mold growth.

Regular cleaning ensures your ice maker operates efficiently and produces clean, fresh ice. For best results, clean the unit every 1-2 months or as needed.

Technical Specifications

The Frigidaire Ice Maker Model EFIC117-SS is designed with advanced features to deliver high performance and efficiency. Below are the key technical specifications:

• Dimensions: 17.5 x 13.5 x 17.5 inches (W x D x H)
• Weight: Approximately 31 pounds
• Ice Production: Produces up to 26 pounds of ice per day
• Ice Basket Capacity: 2.2 pounds
• Water Consumption: Low water usage for efficient operation
• Electrical Requirements: 120V, 60Hz, 2.5A
• Noise Level: Quiet operation at 37 dBA
• Approval: ETL and Energy Star certified
• Warranty: 1-year limited warranty on parts and labor

These specifications ensure the ice maker is both reliable and energy-efficient, making it a great addition to any kitchen or office setting.

Warranty Information

Your Frigidaire Ice Maker Model EFIC117-SS is backed by a comprehensive warranty program designed to protect your investment. Below are the key details:

• 1-Year Limited Warranty: Covers parts and labor for one (1) year from the date of purchase.
• Coverage: The warranty applies to defects in materials and workmanship under normal use and conditions.
• Exclusions: Damage caused by misuse, improper installation, or failure to follow the user manual is not covered.
• Service: Contact Frigidaire Customer Service for warranty claims or repairs.
• Extended Support: Optional extended warranties may be available for purchase.

For full warranty terms and conditions, visit the Frigidaire website or contact their support team. Proper registration of your product ensures seamless warranty service.

Safety Guidelines

Always follow these precautions to ensure safe operation:

• Electrical Safety: Avoid water contact with electrical components.
• Handling: Use care when handling sharp edges or ice.
• Cleaning: Only use recommended cleaning agents.
• Installation: Ensure proper grounding and avoid overloaded circuits.
• Children: Keep children away from moving parts.

7.1. General Safety Precautions

Adhering to safety guidelines is crucial for the safe operation of the Frigidaire Ice Maker Model EFIC117-SS. Always follow these precautions to minimize risks and ensure reliable performance:

• Electrical Safety: Ensure the unit is properly grounded and avoid using damaged power cords or outlets.
• Water Safety: Do not submerge the ice maker in water or expose electrical components to moisture.
• Handling Precautions: Use care when handling ice, as it may cause slipping or injury. Avoid touching sharp edges.
• Cleaning Safety: Only use mild detergents and avoid abrasive cleaners that may damage surfaces or harm users.
• Installation Safety: Ensure the unit is installed on a stable, level surface away from direct sunlight and heat sources.
• Child Safety: Keep children away from moving parts and ensure they do not play with the ice maker.

By following these guidelines, you can ensure a safe and efficient operation of your Frigidaire Ice Maker Model EFIC117-SS.
